Vxl1000w 10Kwh 51.2V 200Ah Powerwall ESS Lifepo4 Battery
Vxl1000w 10Kwh 51.2V 200Ah 6000+ times cycle life Powerwall ESS Lifepo4 Energy Storage Battery Home Power Storage
Battery Type: Advanced lithium iron phosphate battery
Model No: Vxl1000w
Rated voltage: 51.2V
Capacity: 200Ah
Size: 155mmX860mmX485mm
Application: Home ESS,Solar ESS,Solar off grid backup system
Cycle life: 6000+ times at 80% DOD
Product Information
Vxl1000w 10Kwh 51.2V 200Ah Powerwall ESS Lifepo4 battery

There are some applicable scenarios for Vxl10kw powerwall LiFePO4 battery, which can be used in home energy storage battery system, solar ESS, solar off grid backup system, to store and manage electrical energy to provide power supply when needed.

Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery
Vxl1000w Technical Details:
Mode Vxl1000w
Battery Type Lifepo4 battery
Battery Combination 16S1P
Case Numbers 1 pc
Nominal Characteristic
Nominal Voltage 51.2V
Battery Capacity 200Ah
Nominal Energy Capacity 10KWh
Peak Output Current 100A
Round trip Efficiency 96%-99%
Electrical Specifications
Voltage Range 40-58.4V
Max. Charing Current 100A
Max. Discharing Current 100A
Mechanical Specifications
Net Weight 100.0kg
Dimension 155mmX860mmX485mm
Color White
Cooling Nature
Communication Specifications
Communication Port RS485/RS232/CAN
Operation Condition
Operation Temperature -20-65℃
Recommended Temperature 0-65℃
Operation Humidity 60%±25%
Storage Conditions 0~40℃
Certification CE/IEC/UN38.3
Standards EN61000-6-1:2007 EN61000-6-3:2007+A1:2011
Inverter Type Goodwe,Victron Energy,Growatt,Pylontech, Voltronics,Deye,Inhenergy etc
Warranty 3 years
Life design 10+ years
Installation type
Installation type Wall mounted
Cycle life
0.2C  at  room temp 6000+ times( 80% DOD)
0.5C  at room temp 4000+ times( 80% DOD)
1.0C  at room temp 2500+ times( 80% DOD)
 Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery
Manufacturing Technology:

Declaration: VTC Power produces the Vxl10kw powerwall LiFePO4 battery cell by ourselves and insists on using brand new and grade A cells only for safety and best battery pack performance.

Warning: Now lots of other competitors use recycled cells. Recycled cells cant ensure the constancy of the cells and BMS effective management, which will put lots of safety issues and danger in the household.
VTC Power Cell production process:
Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery
VTC Power Battery Pack Assemble process:
Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery
Matching Inverter:
The Vxl10kw powerwall LiFePO4 battery matches multiple brand inverters via RS485/CAN communication protocol. Its RS232 communication protocol can support PC data reading of battery SOH, capacity and battery charge&discharge status. Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery
Discharge&Charge Curve:
Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery
Project Cases:

6000+ families in Germany, Europe, South Africa, Australia choose the Vxl10kw powerwall LiFePO4 battery for their home power supply.

Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery


Vxl1000w 10Kwh Powerwall Ess Lifepo4 battery
