Golf Cart Lithium Battery 72V 105AH

golf cart battery 72V100AH
Golf cart battery 72V100AH 2
Golf cart battery 72V100AH 4
Golf cart battery 72V100AH 3

Golf Cart Lithium Battery 72V 105AH

    • Nominal Voltage: 72V (76.8V)
    • Nominal Capacity: 105 Ah
    • Stored Energy: 8.06 kWh
    • Dimension (L×W×H) In Inch: 26.42 x 14.25 x 9.65 inch
    • Dimension (L×W×H) In Millimeter: 671 × 362 × 245 mm
    • Weight lbs. (kg) No Counterweight: 156.53 lbs (71 kg)
    • Typical Mileage Per Full charge: 91–121 km (57–75 miles)
    • Cycle Life: ＞4,000 Times
    • IP Rating: IP67

  • Long Cycle Life
  • High Energy Density
  • Fast Charging
  • Zero maintenance
  • Compatible with 98% of golf cart models
ENQUIRY NOW
DATA SHEET

Products Details

Safe LiFePO4 Chemistry

Stable, non-flammable lithium iron phosphate ensures safety in industrial environments.

Long Life & High Efficiency

Delivers 3,500–6,000 cycles and charges in 1.5–2.5 hours with 99% efficiency.

Smart Battery Management

Built-in BMS offers real-time monitoring and multi-level protection.

Flexible Voltage & Compatibility

Available in 24V, 36V, 48V, and 72V for all major golf cart types.

Space & Maintenance Saving

No battery room, no watering, no acid—zero maintenance required.

Clean & Durable Design

No gas emissions or spills, IP65-rated for harsh work environments.

Smart Golf Cart Lithium Battery

The smart battery pack (LiFePo4) has smart Advanced BMS patented technology. Multiple protections for voltage current, temperature, and short circuit provide customers with easy and comfortable power supply.

The smart battery is featured with function to monitor automobile battery through mobile app to achieve battenstatus real-time monitor at the users end. The remote diagnosis function is favorable to find out the cause of the problem.

The battery highlighted with high density, small size, light weight and reliable performance is ideal for low speed vehicles, electric utility vehicles and ground cleaning vehicles.

SPECS

Specification 38.4V 105Ah 51.2V 105Ah 51.2V 125Ah 76.8V 105Ah
Nominal Voltage 38.4V 51.2V 51.2V 76.8V
Rated Capacity 105Ah 105Ah 125Ah 105Ah
Continuous Discharge 105A 105A 125A 105A
Max. Discharge Current (30S) 315A 315A 375A 315A
Size (L×W×H) 521×362×245mm 521×362×245mm 612×392×245mm 671×362×245mm
Weight 37Kg 45Kg 54Kg 71Kg
Mileage 48–60KM 64–81KM 80–100KM 91–121KM
Charging Temp. 0–55℃ 0–55℃ 0–55℃ 0–55℃
Discharging Temp. -20–55℃ -20–55℃ -20–55℃ -20–55℃
Storage Temp. (1 year) 0–35℃ 0–35℃ 0–35℃ 0–35℃
Waterproof IP67 IP67 IP67 IP67

Smart Golf Cart Battery Monitor App

Easily monitor your golf cart’s lithium battery status in real-time. Track voltage, SOC, temperature, and more with Bluetooth connectivity, ensuring safety, performance, and extended battery life.

  • Check battery charge level
  • Monitor real-time voltage
  • View temperature readings
  • Track battery health status
  • Receive low-battery alerts
  • Access charge/discharge history
  • Diagnose system faults
  • Remote diagnosis of battery failure

Display

With display and BT monitoring

GPS

Customisod GPS positioning function

Vent Valve

Highest safety for thermal runaway. overcharging,high temp,physical damage

Powerfull

BMS 150A,200A.250A.300A optionol

APP

Bottery stotus can be checked by phone in real time

Support parallel

Connected in parallel for lorger capacity

Waterproof

IP65 and with pressure relief valve

Smart Golf Cart Battery Monitor App

Easily monitor your golf cart’s lithium battery status in real-time. Track voltage, SOC, temperature, and more with Bluetooth connectivity, ensuring safety, performance, and extended battery life.

  • Check battery charge level
  • Monitor real-time voltage
  • View temperature readings
  • Track battery health status
  • Receive low-battery alerts
  • Access charge/discharge history
  • Diagnose system faults
  • Remote diagnosis of battery failure
VTCBATT Golf cart battery User Manual Sheet-APP
VTCBATT Golf cart battery User Manual Sheet-Accessory 1

Install with total conversion kit

Easily upgrade your golf cart with our Total Conversion Kit—complete with wiring, connectors, and instructions for a fast, hassle-free installation.

  • Includes all necessary wiring and connectors
  • Plug-and-play design for easy installation
  • Compatible with most golf cart models
  • No special tools required
  • Step-by-step instructions included

Much better than lead-acid batteries!

Experience longer driving range, quicker recharges, and lightweight power with zero maintenance—engineered for superior performance and reliability in every ride.

  • Longer lifespan, reducing replacement frequency
  • Faster charging times for less downtime
  • Lightweight design improves vehicle efficiency
  • Maintenance-free, no need for watering or equalizing
  • Higher energy density for extended driving range
  • More environmentally friendly and safer chemistry
  • Consistent performance in a wide temperature range
Lead To Lithium 1

Efficient power

Stable quality

Durable

>4000 cycles

0 maintenance

Environmental protection

Safe and reliable

Applications

VTCBATT offers connection accessories fully compatible with diverse golf carts and are accompanied by intuitive and straightforward instructions. Our battery ensures exceptional ease of use.

Suitable for Brands below:

Club Car, E-Z-GO, ICON EV,
Yamaha, EPIC, Honor LSV, Advanced EV, Kodiak, MOKE CARTS, Pilot Car, Polaris, Vivid EV, Bintelli, Others / OEM, ……

VTCBATT smart batteries are compatible with nearly all golf cart models, not limited to only the brands listed above. For specific questions, please contact our customer service to give you satisfactory service. Vehicles suitable for VTCBATT lithium batteries

Battery installation ACCESSORIES

SOC monitor
SOC monitor

Displays real-time voltage, amps, and remaining charge percentage.

Display communication power wire
Display wire

Connect the battery to the battery dashboard and switch using this split cable.

Secure the bracket and screws
Secure bracket and screws

Secured to the chassis with screws through hooks connecting the Battery Body Buckle to the carts.

Waterproof Charger
Battery Charger

Charger with snap attachment, featuring reliability, safety, and short circuit protection.

CAN Cable
CAN Cable

Optional CAN cable for battery communication and BMS parameter adjustments

FAQs for 72v Golf Cart Lithium Battery

What are the main differences between 72V and 48V golf cart batteries?
The main difference between 72V and 48V golf cart batteries lies in their voltage and the performance that voltage enables. A 72V battery has a higher nominal voltage than a 48V battery, which translates into more power, faster acceleration, and better hill-climbing ability. This makes 72V systems ideal for heavier carts or those needing extra performance for rugged terrain or steep courses. However, 72V batteries require compatible controllers, chargers, and wiring designed specifically for the higher voltage to ensure safety and proper operation. If your cart is set up for 48V, you’ll need to upgrade key components to switch to 72V. On the other hand, 48V batteries offer great reliability and efficiency for most standard golf cart uses, often with lower cost and simpler compatibility.
Depending on capacity (for example, 100Ah) and driving conditions like terrain, load, and speed, a 72V golf cart battery typically provides a driving range of about 90 to 120 kilometers (56 to 75 miles) on a full charge. This extended range allows you to play multiple rounds of golf, explore larger communities, or enjoy longer recreational trips without needing to recharge frequently. Compared to 48V systems, the higher voltage not only delivers more power but also gives you the confidence to go further and handle tougher driving conditions with ease.
Generally, no—you cannot simply swap a 72V battery into a golf cart originally designed for 48V. The cart’s controller, wiring, and other electrical components are specifically rated for 48V systems. Using a 72V battery without upgrading these components can damage the electronics, void warranties, and create serious safety risks like overheating or electrical failure. If you want to upgrade to 72V, it requires replacing the controller, charger, and sometimes other parts with components rated for 72V operation. Always consult a professional or your battery supplier before making voltage changes to ensure safe and reliable performance.
With a compatible 72V lithium charger, typically rated between 20 to 30 amps, it usually takes about 6 to 8 hours to fully charge your 72V golf cart battery from empty. Charging time can vary based on the charger’s amperage, the battery’s initial state of charge, and ambient temperature. Thanks to lithium technology, you can also perform faster top-up charges during breaks, letting you get back on the course sooner. Always use a charger matched to your battery to ensure safe, efficient charging and to maximize battery lifespan.
VTCBATT’s 72V lithium batteries are equipped with an advanced Battery Management System (BMS) that acts as a comprehensive safety guardian. This system continuously monitors each cell and protects against potential risks such as overcharging, over-discharging, overcurrent, short circuits, and extreme temperatures (both hot and cold). The BMS also balances the cells to maintain optimal performance and extend battery life. These built-in protections ensure your battery operates safely and reliably, giving you peace of mind whether you’re cruising on the golf course or tackling more demanding terrains.
Yes, 72V batteries are generally larger and heavier than lower voltage options like 48V or 36V batteries. This is because they contain more cells in series to achieve the higher voltage, and often have higher capacity to deliver longer range and more power. As a result, golf carts need to have sufficient physical space and weight capacity to safely accommodate these bigger battery packs. When upgrading or choosing a 72V system, it’s important to verify that your cart’s frame, battery compartment, and suspension can handle the increased size and weight without affecting performance or safety.
Upgrading from a 48V to a 72V battery system offers several key benefits. The higher voltage delivers more power and faster acceleration, making your golf cart quicker off the mark and better able to handle steep hills and challenging terrain with ease. With the right battery capacity and supporting components, you can also enjoy an extended driving range, allowing longer trips between charges. However, this upgrade isn’t just about swapping batteries—it requires compatible controllers, chargers, and possibly other electrical adjustments to ensure safe, reliable operation. When done properly, moving to 72V can transform your golf cart’s performance and efficiency, giving you a more powerful and versatile ride.
